Step2: 安裝前準備
1、改主機名
demon@ubuntu2204-master:~$ sudo vi /etc/hostname
...
demon@ubuntu2204-master:~$ cat /etc/hostname
ubuntu2204-master
demon@ubuntu2204-master:~$2、設置流量轉發
修改 的配置，啟用“”模塊，讓 可以檢查和轉發網絡流量。
cat <
EOF
cat <
net.bridge.bridge-nf-call-iptables = 1
net.ipv4.ip_forward=1 # better than modify /etc/sysctl.conf
EOF
sudo sysctl --system3、關閉 Linux Swap 分區
基于安全性（如在官方文檔中承諾的 只會在內存中讀寫，不會落盤）、利于保證節點同步一致性等原因，從 1.8 版開始，就在它的文檔中明確聲明了它默認不支持 Swap 分區計算機中集群是什么意思，在未關閉 Swap 分區的機器中，集群將直接無法啟動。
sudo cp /etc/fstab /etc/fstab_bak
sudo swapoff -a
sudo sed -ri '/\sswap\s/s/^#?/#/' /etc/fstab4、注冊 apt 軟件源
這里選擇阿里云:
sudo apt install -y apt-transport-https ca-certificates curl
curl https://mirrors.aliyun.com/kubernetes/apt/doc/apt-key.gpg | sudo apt-key add -
cat <
EOF
sudo apt update
Step3: 安裝 , ,
這里先解釋一下這三個工具的作用：
如果不指定版本，則默認安裝最新版本，筆者這里選擇的版本是 1.25.3：
sudo apt install -y kubeadm=1.25.3-00 kubelet=1.25.3-00 kubectl=1.25.3-00鎖定版本，不讓它們自動更新：
demon@ubuntu2204-master:~$ sudo apt-mark hold kubeadm kubelet kubectl
kubeadm set on hold.
kubelet set on hold.
kubectl set on hold.
demon@ubuntu2204-master:~$查看安裝結果：
demon@ubuntu2204-master:~$ kubeadm version
kubeadm version: &version.Info{Major:"1", Minor:"25", GitVersion:"v1.25.3", GitCommit:"434bfd82814af038ad94d62ebe59b133fcb50506", GitTreeState:"clean", BuildDate:"2022-10-12T10:55:36Z", GoVersion:"go1.19.2", Compiler:"gc", Platform:"linux/arm64"}
demon@ubuntu2204-master:~$
demon@ubuntu2204-master:~$ kubectl version
WARNING: This version information is deprecated and will be replaced with the output from kubectl version --short. Use --output=yaml|json to get the full version.
Client Version: version.Info{Major:"1", Minor:"25", GitVersion:"v1.25.3", GitCommit:"434bfd82814af038ad94d62ebe59b133fcb50506", GitTreeState:"clean", BuildDate:"2022-10-12T10:57:26Z", GoVersion:"go1.19.2", Compiler:"gc", Platform:"linux/arm64"}
Kustomize Version: v4.5.7
The connection to the server localhost:8080 was refused - did you specify the right host or port?
demon@ubuntu2204-master:~$
demon@ubuntu2204-master:~$ kubelet --version
Kubernetes v1.25.3
demon@ubuntu2204-master:~$
了解后續需要的鏡像版本：
demon@ubuntu2204-master:~$ sudo kubeadm config images list --kubernetes-version v1.25.3
registry.k8s.io/kube-apiserver:v1.25.3
registry.k8s.io/kube-controller-manager:v1.25.3
registry.k8s.io/kube-scheduler:v1.25.3
registry.k8s.io/kube-proxy:v1.25.3
registry.k8s.io/pause:3.8
registry.k8s.io/etcd:3.5.4-0
registry.k8s.io/coredns/coredns:v1.9.3
demon@ubuntu2204-master:~$
Step4: 初始化集群控制面
1、啟動 ，保證開機執行
$ sudo systemctl start kubelet
$ sudo systemctl enable kubelet2、開始部署，這里切換到 root 賬號，而不是使用sudo
kubeadm init \
--image-repository registry.cn-hangzhou.aliyuncs.com/google_containers \
--pod-network-cidr=10.10.0.0/16 \
--apiserver-advertise-address=192.168.10.128 \
--kubernetes-version=v1.25.3 \
--v=5
解釋一下這里的幾個參數：
安裝日志：
root@ubuntu2204-master:~# kubeadm init \
--image-repository registry.cn-hangzhou.aliyuncs.com/google_containers \
--pod-network-cidr=10.10.0.0/16 \
--apiserver-advertise-address=192.168.10.128 \
--kubernetes-version=v1.25.3 \
> --v=5
I1116 15:56:26.815643 2036 initconfiguration.go:116] detected and using CRI socket: unix:///var/run/containerd/containerd.sock
I1116 15:56:26.815827 2036 kubelet.go:196] the value of KubeletConfiguration.cgroupDriver is empty; setting it to "systemd"
[init] Using Kubernetes version: v1.25.3
[preflight] Running pre-flight checks
I1116 15:56:26.819499 2036 checks.go:568] validating Kubernetes and kubeadm version
I1116 15:56:26.819566 2036 checks.go:168] validating if the firewall is enabled and active
I1116 15:56:26.825072 2036 checks.go:203] validating availability of port 6443
I1116 15:56:26.825237 2036 checks.go:203] validating availability of port 10259
I1116 15:56:26.825299 2036 checks.go:203] validating availability of port 10257
I1116 15:56:26.825384 2036 checks.go:280] validating the existence of file /etc/kubernetes/manifests/kube-apiserver.yaml
I1116 15:56:26.825516 2036 checks.go:280] validating the existence of file /etc/kubernetes/manifests/kube-controller-manager.yaml
I1116 15:56:26.825620 2036 checks.go:280] validating the existence of file /etc/kubernetes/manifests/kube-scheduler.yaml
I1116 15:56:26.825673 2036 checks.go:280] validating the existence of file /etc/kubernetes/manifests/etcd.yaml
I1116 15:56:26.825728 2036 checks.go:430] validating if the connectivity type is via proxy or direct
I1116 15:56:26.825843 2036 checks.go:469] validating http connectivity to first IP address in the CIDR
I1116 15:56:26.825911 2036 checks.go:469] validating http connectivity to first IP address in the CIDR
I1116 15:56:26.825960 2036 checks.go:104] validating the container runtime
I1116 15:56:26.887241 2036 checks.go:329] validating the contents of file /proc/sys/net/bridge/bridge-nf-call-iptables
I1116 15:56:26.887388 2036 checks.go:329] validating the contents of file /proc/sys/net/ipv4/ip_forward
I1116 15:56:26.887405 2036 checks.go:644] validating whether swap is enabled or not
I1116 15:56:26.887455 2036 checks.go:370] validating the presence of executable crictl
I1116 15:56:26.887494 2036 checks.go:370] validating the presence of executable conntrack
I1116 15:56:26.887521 2036 checks.go:370] validating the presence of executable ip
I1116 15:56:26.887557 2036 checks.go:370] validating the presence of executable iptables
I1116 15:56:26.887614 2036 checks.go:370] validating the presence of executable mount
I1116 15:56:26.887661 2036 checks.go:370] validating the presence of executable nsenter
I1116 15:56:26.887701 2036 checks.go:370] validating the presence of executable ebtables
I1116 15:56:26.887738 2036 checks.go:370] validating the presence of executable ethtool
I1116 15:56:26.887766 2036 checks.go:370] validating the presence of executable socat
I1116 15:56:26.887809 2036 checks.go:370] validating the presence of executable tc
I1116 15:56:26.887844 2036 checks.go:370] validating the presence of executable touch
I1116 15:56:26.887855 2036 checks.go:516] running all checks
[WARNING SystemVerification]: missing optional cgroups: blkio
I1116 15:56:26.896081 2036 checks.go:401] checking whether the given node name is valid and reachable using net.LookupHost
I1116 15:56:26.896538 2036 checks.go:610] validating kubelet version
I1116 15:56:26.935223 2036 checks.go:130] validating if the "kubelet" service is enabled and active
I1116 15:56:26.947920 2036 checks.go:203] validating availability of port 10250
I1116 15:56:26.948061 2036 checks.go:203] validating availability of port 2379
I1116 15:56:26.948111 2036 checks.go:203] validating availability of port 2380
I1116 15:56:26.948157 2036 checks.go:243] validating the existence and emptiness of directory /var/lib/etcd
[preflight] Pulling images required for setting up a Kubernetes cluster
[preflight] This might take a minute or two, depending on the speed of your internet connection
[preflight] You can also perform this action in beforehand using 'kubeadm config images pull'
I1116 15:56:26.948474 2036 checks.go:832] using image pull policy: IfNotPresent
I1116 15:56:26.964706 2036 checks.go:841] image exists: registry.cn-hangzhou.aliyuncs.com/google_containers/kube-apiserver:v1.25.3
I1116 15:56:26.978755 2036 checks.go:841] image exists: registry.cn-hangzhou.aliyuncs.com/google_containers/kube-controller-manager:v1.25.3
I1116 15:56:27.000585 2036 checks.go:841] image exists: registry.cn-hangzhou.aliyuncs.com/google_containers/kube-scheduler:v1.25.3
I1116 15:56:27.017285 2036 checks.go:841] image exists: registry.cn-hangzhou.aliyuncs.com/google_containers/kube-proxy:v1.25.3
I1116 15:56:27.032953 2036 checks.go:841] image exists: registry.cn-hangzhou.aliyuncs.com/google_containers/pause:3.8
I1116 15:56:27.048539 2036 checks.go:841] image exists: registry.cn-hangzhou.aliyuncs.com/google_containers/etcd:3.5.4-0
I1116 15:56:27.064166 2036 checks.go:841] image exists: registry.cn-hangzhou.aliyuncs.com/google_containers/coredns:v1.9.3
[certs] Using certificateDir folder "/etc/kubernetes/pki"
I1116 15:56:27.064309 2036 certs.go:112] creating a new certificate authority for ca
[certs] Generating "ca" certificate and key
I1116 15:56:27.115296 2036 certs.go:522] validating certificate period for ca certificate
[certs] Generating "apiserver" certificate and key
[certs] apiserver serving cert is signed for DNS names [kubernetes kubernetes.default kubernetes.default.svc kubernetes.default.svc.cluster.local ubuntu2204-master] and IPs [10.96.0.1 192.168.10.128]
[certs] Generating "apiserver-kubelet-client" certificate and key
I1116 15:56:27.397793 2036 certs.go:112] creating a new certificate authority for front-proxy-ca
[certs] Generating "front-proxy-ca" certificate and key
I1116 15:56:27.611526 2036 certs.go:522] validating certificate period for front-proxy-ca certificate
[certs] Generating "front-proxy-client" certificate and key
I1116 15:56:27.756970 2036 certs.go:112] creating a new certificate authority for etcd-ca
[certs] Generating "etcd/ca" certificate and key
I1116 15:56:27.825701 2036 certs.go:522] validating certificate period for etcd/ca certificate
[certs] Generating "etcd/server" certificate and key
[certs] etcd/server serving cert is signed for DNS names [localhost ubuntu2204-master] and IPs [192.168.10.128 127.0.0.1 ::1]
[certs] Generating "etcd/peer" certificate and key
[certs] etcd/peer serving cert is signed for DNS names [localhost ubuntu2204-master] and IPs [192.168.10.128 127.0.0.1 ::1]
[certs] Generating "etcd/healthcheck-client" certificate and key
[certs] Generating "apiserver-etcd-client" certificate and key
I1116 15:56:28.545309 2036 certs.go:78] creating new public/private key files for signing service account users
[certs] Generating "sa" key and public key
[kubeconfig] Using kubeconfig folder "/etc/kubernetes"
I1116 15:56:28.708973 2036 kubeconfig.go:103] creating kubeconfig file for admin.conf
[kubeconfig] Writing "admin.conf" kubeconfig file
I1116 15:56:28.784633 2036 kubeconfig.go:103] creating kubeconfig file for kubelet.conf
[kubeconfig] Writing "kubelet.conf" kubeconfig file
I1116 15:56:28.848427 2036 kubeconfig.go:103] creating kubeconfig file for controller-manager.conf
[kubeconfig] Writing "controller-manager.conf" kubeconfig file
I1116 15:56:29.059470 2036 kubeconfig.go:103] creating kubeconfig file for scheduler.conf
[kubeconfig] Writing "scheduler.conf" kubeconfig file
I1116 15:56:29.185240 2036 kubelet.go:66] Stopping the kubelet
[kubelet-start] Writing kubelet environment file with flags to file "/var/lib/kubelet/kubeadm-flags.env"
[kubelet-start] Writing kubelet configuration to file "/var/lib/kubelet/config.yaml"
[kubelet-start] Starting the kubelet
[control-plane] Using manifest folder "/etc/kubernetes/manifests"
[control-plane] Creating static Pod manifest for "kube-apiserver"
I1116 15:56:29.363351 2036 manifests.go:99] [control-plane] getting StaticPodSpecs
I1116 15:56:29.363501 2036 certs.go:522] validating certificate period for CA certificate
I1116 15:56:29.363535 2036 manifests.go:125] [control-plane] adding volume "ca-certs" for component "kube-apiserver"
I1116 15:56:29.363538 2036 manifests.go:125] [control-plane] adding volume "etc-ca-certificates" for component "kube-apiserver"
I1116 15:56:29.363541 2036 manifests.go:125] [control-plane] adding volume "etc-pki" for component "kube-apiserver"
I1116 15:56:29.363543 2036 manifests.go:125] [control-plane] adding volume "k8s-certs" for component "kube-apiserver"
I1116 15:56:29.363546 2036 manifests.go:125] [control-plane] adding volume "usr-local-share-ca-certificates" for component "kube-apiserver"
I1116 15:56:29.363549 2036 manifests.go:125] [control-plane] adding volume "usr-share-ca-certificates" for component "kube-apiserver"
I1116 15:56:29.364668 2036 manifests.go:154] [control-plane] wrote static Pod manifest for component "kube-apiserver" to "/etc/kubernetes/manifests/kube-apiserver.yaml"
[control-plane] Creating static Pod manifest for "kube-controller-manager"
I1116 15:56:29.364676 2036 manifests.go:99] [control-plane] getting StaticPodSpecs
I1116 15:56:29.364760 2036 manifests.go:125] [control-plane] adding volume "ca-certs" for component "kube-controller-manager"
I1116 15:56:29.364764 2036 manifests.go:125] [control-plane] adding volume "etc-ca-certificates" for component "kube-controller-manager"
I1116 15:56:29.364766 2036 manifests.go:125] [control-plane] adding volume "etc-pki" for component "kube-controller-manager"
I1116 15:56:29.364769 2036 manifests.go:125] [control-plane] adding volume "flexvolume-dir" for component "kube-controller-manager"
I1116 15:56:29.364771 2036 manifests.go:125] [control-plane] adding volume "k8s-certs" for component "kube-controller-manager"
I1116 15:56:29.364773 2036 manifests.go:125] [control-plane] adding volume "kubeconfig" for component "kube-controller-manager"
I1116 15:56:29.364776 2036 manifests.go:125] [control-plane] adding volume "usr-local-share-ca-certificates" for component "kube-controller-manager"
I1116 15:56:29.364778 2036 manifests.go:125] [control-plane] adding volume "usr-share-ca-certificates" for component "kube-controller-manager"
I1116 15:56:29.365051 2036 manifests.go:154] [control-plane] wrote static Pod manifest for component "kube-controller-manager" to "/etc/kubernetes/manifests/kube-controller-manager.yaml"
[control-plane] Creating static Pod manifest for "kube-scheduler"
I1116 15:56:29.365056 2036 manifests.go:99] [control-plane] getting StaticPodSpecs
I1116 15:56:29.365124 2036 manifests.go:125] [control-plane] adding volume "kubeconfig" for component "kube-scheduler"
I1116 15:56:29.365267 2036 manifests.go:154] [control-plane] wrote static Pod manifest for component "kube-scheduler" to "/etc/kubernetes/manifests/kube-scheduler.yaml"
[etcd] Creating static Pod manifest for local etcd in "/etc/kubernetes/manifests"
I1116 15:56:29.365641 2036 local.go:65] [etcd] wrote Static Pod manifest for a local etcd member to "/etc/kubernetes/manifests/etcd.yaml"
I1116 15:56:29.365685 2036 waitcontrolplane.go:83] [wait-control-plane] Waiting for the API server to be healthy
[wait-control-plane] Waiting for the kubelet to boot up the control plane as static Pods from directory "/etc/kubernetes/manifests". This can take up to 4m0s
[apiclient] All control plane components are healthy after 4.501675 seconds
I1116 15:56:33.870817 2036 uploadconfig.go:110] [upload-config] Uploading the kubeadm ClusterConfiguration to a ConfigMap
[upload-config] Storing the configuration used in ConfigMap "kubeadm-config" in the "kube-system" Namespace
I1116 15:56:33.876187 2036 uploadconfig.go:124] [upload-config] Uploading the kubelet component config to a ConfigMap
[kubelet] Creating a ConfigMap "kubelet-config" in namespace kube-system with the configuration for the kubelets in the cluster
I1116 15:56:33.880965 2036 uploadconfig.go:129] [upload-config] Preserving the CRISocket information for the control-plane node
I1116 15:56:33.880980 2036 patchnode.go:31] [patchnode] Uploading the CRI Socket information "unix:///var/run/containerd/containerd.sock" to the Node API object "ubuntu2204-master" as an annotation
[upload-certs] Skipping phase. Please see --upload-certs
[mark-control-plane] Marking the node ubuntu2204-master as control-plane by adding the labels: [node-role.kubernetes.io/control-plane node.kubernetes.io/exclude-from-external-load-balancers]
[mark-control-plane] Marking the node ubuntu2204-master as control-plane by adding the taints [node-role.kubernetes.io/control-plane:NoSchedule]
[bootstrap-token] Using token: xic9xj.h4m8entuwgbz92m4
[bootstrap-token] Configuring bootstrap tokens, cluster-info ConfigMap, RBAC Roles
[bootstrap-token] Configured RBAC rules to allow Node Bootstrap tokens to get nodes
[bootstrap-token] Configured RBAC rules to allow Node Bootstrap tokens to post CSRs in order for nodes to get long term certificate credentials
[bootstrap-token] Configured RBAC rules to allow the csrapprover controller automatically approve CSRs from a Node Bootstrap Token
[bootstrap-token] Configured RBAC rules to allow certificate rotation for all node client certificates in the cluster
[bootstrap-token] Creating the "cluster-info" ConfigMap in the "kube-public" namespace
I1116 15:56:34.939896 2036 clusterinfo.go:47] [bootstrap-token] loading admin kubeconfig
I1116 15:56:34.940276 2036 clusterinfo.go:58] [bootstrap-token] copying the cluster from admin.conf to the bootstrap kubeconfig
I1116 15:56:34.940432 2036 clusterinfo.go:70] [bootstrap-token] creating/updating ConfigMap in kube-public namespace
I1116 15:56:34.942150 2036 clusterinfo.go:84] creating the RBAC rules for exposing the cluster-info ConfigMap in the kube-public namespace
I1116 15:56:34.945159 2036 kubeletfinalize.go:90] [kubelet-finalize] Assuming that kubelet client certificate rotation is enabled: found "/var/lib/kubelet/pki/kubelet-client-current.pem"
[kubelet-finalize] Updating "/etc/kubernetes/kubelet.conf" to point to a rotatable kubelet client certificate and key
I1116 15:56:34.945791 2036 kubeletfinalize.go:134] [kubelet-finalize] Restarting the kubelet to enable client certificate rotation
[addons] Applied essential addon: CoreDNS
[addons] Applied essential addon: kube-proxy
Your Kubernetes control-plane has initialized successfully!
To start using your cluster, you need to run the following as a regular user:
mkdir -p $HOME/.kube
sudo cp -i /etc/kubernetes/admin.conf $HOME/.kube/config
sudo chown $(id -u):$(id -g) $HOME/.kube/config
Alternatively, if you are the root user, you can run:
export KUBECONFIG=/etc/kubernetes/admin.conf
You should now deploy a pod network to the cluster.
Run "kubectl apply -f [podnetwork].yaml" with one of the options listed at:
https://kubernetes.io/docs/concepts/cluster-administration/addons/
Then you can join any number of worker nodes by running the following on each as root:
kubeadm join 192.168.10.128:6443 --token tu3oa9.o08w1z4c8yfrkoxi \
--discovery-token-ca-cert-hash sha256:b09777337820602596abd84012da770ec8b1637dbdd157e73e765ba0c7790d2b
root@ubuntu2204-master:~#
3、按照上面日志最后部分給的提示進行 kube 配置
mkdir -p $HOME/.kube
sudo cp -i /etc/kubernetes/admin.conf $HOME/.kube/config
sudo chown $(id -u):$(id -g) $HOME/.kube/config
如果是 root 用戶，可以將下面這行加入 .，重新登錄后生效。
export KUBECONFIG=/etc/kubernetes/admin.conf
Step5: 安裝網絡插件
將底層容器網絡抽象成了 CNI[5]，即容器網絡插件：
CNI ( ), a Cloud , of a and for to in Linux , along with a of . CNI only with of and when the is . of this focus, CNI has a wide range of and the is to .
官方列出了非常多的網絡插件，比如 ，Weave，， 等，不同插件的底層原理和實現方式有所不同，但都遵循 CNI 規范。作為入門學習，筆者這里選擇最簡單的 插件。我們從 獲取安裝文件 kube-.yml[6]，然后對其進行修改：
net-conf.json: |
{
"Network": "10.244.0.0/16",
"Backend": {
"Type": "vxlan"
}
}
將上面的 調整為我們之前初始化集群時設置的 pod 網段：
net-conf.json: |
{
"Network": "10.10.0.0/16",
"Backend": {
"Type": "vxlan"
}
}
最后我們使用 apply進行安裝：
kubectl apply -f kube-flannel.yml
Step6：優化（可選）
移除 上的污點
移除污點是為了讓 節點可以部署業務服務[7]：
demon@ubuntu2204-master:~$ kubectl describe node ubuntu2204-master
Name: ubuntu2204-master
Roles: control-plane
Labels: beta.kubernetes.io/arch=arm64
beta.kubernetes.io/os=linux
kubernetes.io/arch=arm64
kubernetes.io/hostname=ubuntu2204-master
kubernetes.io/os=linux
node-role.kubernetes.io/control-plane=
node.kubernetes.io/exclude-from-external-load-balancers=
Annotations: flannel.alpha.coreos.com/backend-data: {"VNI":1,"VtepMAC":"1a:9b:f1:7d:dd:c4"}
flannel.alpha.coreos.com/backend-type: vxlan
flannel.alpha.coreos.com/kube-subnet-manager: true
flannel.alpha.coreos.com/public-ip: 192.168.10.128
kubeadm.alpha.kubernetes.io/cri-socket: unix:///var/run/containerd/containerd.sock
node.alpha.kubernetes.io/ttl: 0
volumes.kubernetes.io/controller-managed-attach-detach: true
CreationTimestamp: Wed, 16 Nov 2022 15:56:32 +0800
Taints: node-role.kubernetes.io/control-plane:NoSchedule
Unschedulable: false
Lease:
HolderIdentity: ubuntu2204-master
AcquireTime:
RenewTime: Wed, 16 Nov 2022 21:33:49 +0800
Conditions:
...
...
...找到: node-role..io/-plane:[8]，然后將其移除：
demon@ubuntu2204-master:~$ kubectl taint nodes ubuntu2204-master node-role.kubernetes.io/control-plane:NoSchedule-
node/ubuntu2204-master untainted
demon@ubuntu2204-master:~$
啟用 命令自動補全功能
bash:
$ echo 'source <(kubectl completion bash)' >> ~/.bashrc
$ echo 'source /usr/share/bash-completion/bash_completion' >> ~/.bashrczsh:
$ echo 'source <(kubectl completion zsh)' >> ~/.zshrc
調整 范圍
默認的 范圍為 30000-32767，本地開發調試可以將其調大一些。
export apiserver_pods=$(kubectl get pods --selector=component=kube-apiserver -n kube-system --output=jsonpath={.items..metadata.name})
kubectl delete pod $apiserver_pods -n kube-system$ kubectl describe pod $apiserver_pods -n kube-system | grep 5000
--service-node-port-range=5000-32767Step7：增加 節點
節點的基礎安裝部分與 節點一致，我們安裝到Step 3就夠了。
接著將 修改為默認啟動：
sudo systemctl enable kubelet然后在當前 節點上運行下面的命令加入集群：
kubeadm join 192.168.10.128:6443 --token tu3oa9.o08w1z4c8yfrkoxi \
--discovery-token-ca-cert-hash sha256:b09777337820602596abd84012da770ec8b1637dbdd157e73e765ba0c7790d2b該命令來自前面Step 4中 init最后的日志：
Then you can join any number of worker nodes by running the following on each as root:
kubeadm join 192.168.10.128:6443 --token tu3oa9.o08w1z4c8yfrkoxi \
--discovery-token-ca-cert-hash sha256:b09777337820602596abd84012da770ec8b1637dbdd157e73e765ba0c7790d2b
上面的 token 有效期為 24 小時，如果過期可以使用如下命令重新生成：
kubeadm token create --print-join-command節點加入日志：
root@ubuntu2204-worker:~# kubeadm join 192.168.10.128:6443 --token tu3oa9.o08w1z4c8yfrkoxi --discovery-token-ca-cert-hash sha256:b09777337820602596abd84012da770ec8b1637dbdd157e73e765ba0c7790d2b --v=5
I1117 09:49:35.953178 2006 join.go:416] [preflight] found NodeName empty; using OS hostname as NodeName
I1117 09:49:35.953532 2006 initconfiguration.go:116] detected and using CRI socket: unix:///var/run/containerd/containerd.sock
[preflight] Running pre-flight checks
I1117 09:49:35.953605 2006 preflight.go:92] [preflight] Running general checks
I1117 09:49:35.953661 2006 checks.go:280] validating the existence of file /etc/kubernetes/kubelet.conf
I1117 09:49:35.953673 2006 checks.go:280] validating the existence of file /etc/kubernetes/bootstrap-kubelet.conf
I1117 09:49:35.953710 2006 checks.go:104] validating the container runtime
I1117 09:49:35.974555 2006 checks.go:329] validating the contents of file /proc/sys/net/bridge/bridge-nf-call-iptables
I1117 09:49:35.974601 2006 checks.go:329] validating the contents of file /proc/sys/net/ipv4/ip_forward
I1117 09:49:35.974626 2006 checks.go:644] validating whether swap is enabled or not
I1117 09:49:35.974645 2006 checks.go:370] validating the presence of executable crictl
I1117 09:49:35.974659 2006 checks.go:370] validating the presence of executable conntrack
I1117 09:49:35.974666 2006 checks.go:370] validating the presence of executable ip
I1117 09:49:35.974674 2006 checks.go:370] validating the presence of executable iptables
I1117 09:49:35.974682 2006 checks.go:370] validating the presence of executable mount
I1117 09:49:35.974689 2006 checks.go:370] validating the presence of executable nsenter
I1117 09:49:35.974698 2006 checks.go:370] validating the presence of executable ebtables
I1117 09:49:35.974707 2006 checks.go:370] validating the presence of executable ethtool
I1117 09:49:35.974714 2006 checks.go:370] validating the presence of executable socat
I1117 09:49:35.974720 2006 checks.go:370] validating the presence of executable tc
I1117 09:49:35.974725 2006 checks.go:370] validating the presence of executable touch
I1117 09:49:35.974750 2006 checks.go:516] running all checks
[WARNING SystemVerification]: missing optional cgroups: blkio
I1117 09:49:35.983005 2006 checks.go:401] checking whether the given node name is valid and reachable using net.LookupHost
I1117 09:49:35.984761 2006 checks.go:610] validating kubelet version
I1117 09:49:36.030854 2006 checks.go:130] validating if the "kubelet" service is enabled and active
I1117 09:49:36.038685 2006 checks.go:203] validating availability of port 10250
I1117 09:49:36.038781 2006 checks.go:280] validating the existence of file /etc/kubernetes/pki/ca.crt
I1117 09:49:36.038789 2006 checks.go:430] validating if the connectivity type is via proxy or direct
I1117 09:49:36.038821 2006 join.go:533] [preflight] Discovering cluster-info
I1117 09:49:36.038862 2006 token.go:80] [discovery] Created cluster-info discovery client, requesting info from "192.168.10.128:6443"
I1117 09:49:36.050731 2006 token.go:118] [discovery] Requesting info from "192.168.10.128:6443" again to validate TLS against the pinned public key
I1117 09:49:36.054719 2006 token.go:135] [discovery] Cluster info signature and contents are valid and TLS certificate validates against pinned roots, will use API Server "192.168.10.128:6443"
I1117 09:49:36.054738 2006 discovery.go:52] [discovery] Using provided TLSBootstrapToken as authentication credentials for the join process
I1117 09:49:36.054743 2006 join.go:547] [preflight] Fetching init configuration
I1117 09:49:36.054747 2006 join.go:593] [preflight] Retrieving KubeConfig objects
[preflight] Reading configuration from the cluster...
[preflight] FYI: You can look at this config file with 'kubectl -n kube-system get cm kubeadm-config -o yaml'
I1117 09:49:36.057469 2006 kubelet.go:74] attempting to download the KubeletConfiguration from ConfigMap "kubelet-config"
I1117 09:49:36.059173 2006 interface.go:432] Looking for default routes with IPv4 addresses
I1117 09:49:36.059196 2006 interface.go:437] Default route transits interface "ens160"
I1117 09:49:36.059274 2006 interface.go:209] Interface ens160 is up
I1117 09:49:36.059298 2006 interface.go:257] Interface "ens160" has 2 addresses :[192.168.10.129/24 fe80::b87b:4a27:cd99:16ee/64].
I1117 09:49:36.059309 2006 interface.go:224] Checking addr 192.168.10.129/24.
I1117 09:49:36.059313 2006 interface.go:231] IP found 192.168.10.129
I1117 09:49:36.059316 2006 interface.go:263] Found valid IPv4 address 192.168.10.129 for interface "ens160".
I1117 09:49:36.059320 2006 interface.go:443] Found active IP 192.168.10.129
I1117 09:49:36.062265 2006 preflight.go:103] [preflight] Running configuration dependant checks
I1117 09:49:36.062285 2006 controlplaneprepare.go:220] [download-certs] Skipping certs download
I1117 09:49:36.062290 2006 kubelet.go:120] [kubelet-start] writing bootstrap kubelet config file at /etc/kubernetes/bootstrap-kubelet.conf
I1117 09:49:36.062705 2006 kubelet.go:135] [kubelet-start] writing CA certificate at /etc/kubernetes/pki/ca.crt
I1117 09:49:36.062997 2006 kubelet.go:156] [kubelet-start] Checking for an existing Node in the cluster with name "ubuntu2204-worker" and status "Ready"
I1117 09:49:36.066958 2006 kubelet.go:171] [kubelet-start] Stopping the kubelet
[kubelet-start] Writing kubelet configuration to file "/var/lib/kubelet/config.yaml"
[kubelet-start] Writing kubelet environment file with flags to file "/var/lib/kubelet/kubeadm-flags.env"
[kubelet-start] Starting the kubelet
[kubelet-start] Waiting for the kubelet to perform the TLS Bootstrap...
I1117 09:49:41.283287 2006 cert_rotation.go:137] Starting client certificate rotation controller
I1117 09:49:41.285117 2006 kubelet.go:219] [kubelet-start] preserving the crisocket information for the node
I1117 09:49:41.285176 2006 patchnode.go:31] [patchnode] Uploading the CRI Socket information "unix:///var/run/containerd/containerd.sock" to the Node API object "ubuntu2204-worker" as an annotation
This node has joined the cluster:
* Certificate signing request was sent to apiserver and a response was received.
* The Kubelet was informed of the new secure connection details.
Run 'kubectl get nodes' on the control-plane to see this node join the cluster.
root@ubuntu2204-worker:~#
最后，如果想在 節點上運行 命令，需要將 節點上的~/.kube/復制過來，然后便可以運行以下命令查看節點信息：
kubectl get nodes小結
相信通過這些步驟，大家開始能體會到其內部的復雜度了，確實不亞于安裝一個操作系統。筆者這里只貼出了主要的執行步驟，其實還有很多可選操作，比如 ， 等，將來有機會，筆者會在其他文章中進行補充。
不過，話又說回來，這么復雜的東西都是由計算機基礎知識構建起來的，比如計算機網絡、操作系統等。正如一座龐大的建筑是由一磚一瓦搭起來的計算機中集群是什么意思，而這一磚一瓦就是基本功。所以，構建基本功是每個計算機工程師、架構師不可或缺的能力。
寫到這里，突然想起一句話：所謂才華，就是基本功的溢出。
[1]
[2]
[3]
[4]#---and-
[5]
[6]
[7] 這里只是為了學習，所以將污點移除，生產環境不建議移除。另外，我們可以在部署業務時，在 Pod 里設置 來“容忍”某些“污點”，也能達到相同的效果。
[8] 在 1.24 之前， 使用node-role..io/:來表示不被調度的污點，之后便調整成了node-role..io/-plane:。
